W Rubber Fenders Overview
W Type Rubber Fender is a high-performance marine shock-absorbing device, characterized by its distinctive W-shaped cross-section with dual parallel hollow cavities. It is typically manufactured from high-quality natural rubber, EPDM, or SBR compounds for superior resilience and marine durability.
Key Specifications
Shape: W-shaped cross-section with open bone design
Construction: Compression-molded solid rubber with twin-leg attachment
Height Range : 300mm – 600mm
Length Range: 500mm – 2,500mm
Products Details
Twin-Leg & Open Bore Design
Grooved Contact Surface
High Compression Deflection
Flexible & Conformable
|
Model |
Width A (mm) |
Base Width B (mm) |
Height H (mm) |
Leg Spacing D (mm) |
Weight (kg/m) |
Max Length (mm) |
|
W320200 |
320 |
200 |
100 |
180 |
51.0 |
2,000 |
|
W400250 |
400 |
250 |
110 |
220 |
81.0 |
2,000 |
|
W480300 |
480 |
300 |
135 |
265 |
120.0 |
2,000 |
|
W500360 |
500 |
360 |
125 |
260 |
156.0 |
2,000 |
|
W500400 |
500 |
400 |
170 |
295 |
165.0 |
2,000 |
|
W500450 |
500 |
450 |
90 |
250 |
180.0 |
2,000 |
Application Areas
Ocean-going tugs: Bow and stern protection during ship-assist and towing
Large harbor tugs: Daily pushing operations in busy ports
Icebreakers: Extreme condition operations
Bridge and pile protection: Structural impact protection
Workboats and pushboats: General pushing and towing duties
